Robot Arm Components
Robot servo 25kg RDS3225 metal gear digital servo
arduino servo with Long and Short Straight U Mouting
Package contains:
1 pieces of RDS3225 Digital Metal Robotic Servo
1 pieces of long U metal brackets
1 pieces of short U metal brackets
1 pieces of metal servo arm 25T
1 pieces of metal servo arm driven
one set of screw(see the picture)
Size:40*20*40.5(servo)
64*55.6*20(Assembly the metal brackets size)
Weight:60g
Wire length:320mm
Speed: 0.19sec/60 degree at(5v)
0.17sec/60 degree at(6.8v)
Torque: 24kg.cm.at(5v)
28kg.cm.at(6.8v)
Voltage: 4.8v-6.8v
Dead Zoon setting:3 Microseconds
Features:
- Durable Metal Gear
- Dual Ball Bearing
- Programmable Digital Amplifier with Mosft Drive
- Bottom Side Axial Mount Hole
- Original factory product
- Less Noise
-Contains: Long Holder Aluminum & Short Holder Aluminum &
Circle Holder-25T & Circle Holder -Orientation Angle:maximum
180 deg
-Mechanical Angle :360 deg
$32 USA
Robot servo 15kg RDS3115 metal gear digital servo arduino servo
with Long and Short Straight U mounting
Package contains:
1 pieces of RDS3115 Digital Metal Robotic Servo
1 pieces of long U metal brackets
1 pieces of short U metal brackets
1 pieces of metal servo arm 25T
1 pieces of metal servo arm driven
one set of screws
Size:40*20*40.5(servo)\
64*55.6*20(Assembly the metal brackets size)
Weight:60g
Wire length:320mm
Speed: 0.16sec/60 degree at(5v)
0.14sec/60 degree at(6.8v)
Torque: 15kg.cm.at(5v)
17kg.cm.at(6.8v)
Voltage: 4.8v-6.8v
Dead Zoon setting:3 Microseconds
Features:
- Durable Metal Gear
- Dual Ball Bearing
- Programmable Digital Amplifier with Mosft Drive
- Bottom Side Axial Mount Hole
- Original factory product
- Less Noise
-Contains: Long Holder Aluminum & Short Holder Aluminum & Circle
Holder-25T & Circle Holder -Orientation Angle:maximum 180 deg
-Mechanical Angle :360 deg
$27 USA
Arduino Robot Base 2 DOF Servo PTZ Camera
Photography Turntable Turntable Chassis Mount Kit
Traditional simple 2-degree-of-freedom PTZ,The output shaft of the
steering gear as a support, force is entirely in the steering gear output
shaft,Can only carry a small weight,2 degrees of freedom PTZ,The
bracket accessories part of use 2mm thick 6061-hard aluminum
alloy,assort large round bearings and copper pillar,Stable and smooth
rotation,Strong load-bearing capacity.
We use two high torque metal gear servo as the power source,Have
the PTZ horizontal rotation of 180 degrees or 360 degrees and 180
degrees vertical rotation.
Products do not contain servo(please tell us what color you need when place order, silver or black.)
Packing list:
1 x rotating base alloy
1 x multi-bracket
1 x long U-bracket
1 x Cup disabilities bearing
1 x The supporting screw nut sets
4 x 30mm copper cylinder
(Not assembled,Mount Kit only, Servo & Electronic Parts shown in picture are NOT include.)
$69 USA
MG90S 9g Metal Gear Mini Rc Servo
Upgraded SG90 Micro Servos
Product Model: MG90S
Working torque: 2KG/cm
Reaction speed: 0.11 seconds / 60 degrees (4.8V
Operating temperature: 0 -55
The dead band setting: 5 microseconds
Plug Type: JR, FUTABA General
Rotation angle: 180 degrees
Servo: analog Servo
Operating voltage: 4.8V
Structural Material: copper metal teeth, coreless
motor, double ball bearing
Scope: small and medium-sized electric model aircraft
and model.
The attachment contains: helm, the line is long 30CM,
fixing screws, damping pouches and aluminum sets
and other accessories (see really making plans)
Color: As the picture
Weight:14.4g
$12 USA
Enigma Control
Panel
$250 USA
Enigma Bogglers
Prices in USA Dollars
Audio Boggler $35
Motor Control Boggler $35
On Off Control Boggler $35
Servo Boggler for 5 Servo’s $45
Extension Servo Boggler for extra 5 Servo’s $25
